# Escaping from Earth

#### Understanding the Gravity of the situation

To escape the Earth and travel into space, one has to overcome its gravitational pull.

From experimental data it can be shown that:

1.  There is a gravitational pull between all bodies with mass.  They attract each other.

2.  Bodies with large masses have large pull.  So big planets have high gravity.

3.  The further they are from each other the smaller the gravitational pull between them.

4.  Results show that at twice the distance the gravitational pull between the bodies is ¼.

At 3 times the distance, the pull is one ninth.  This is called an 'INVERSE SQUARE' law.

#### <p>iframes are not supported by your browser.</p>

The Moon is smaller than the Earth, so its gravitational pull is less than the Earth's.  A person on the Moon can lift 5 times as much more weight as on Earth.  The same weight will crush him on Jupiter.

Continue... Artificial Satellites

#### Satellites

What happens when you throw a ball horizontally

Q.  Why doesn't the ball move in a straight line.

Q.  What will happen if you throw the ball faster and harder

Q.  What will happen if you fired a bullet horizontally out of a gun.

So, lets have a look!

#### <p>iframes are not supported by your browser.</p>

If an object is fired at 8Km/s, 25 times the speed of sound, then it would still fall towards Earth, but it would stay the same height above the earth's surface, because of the curving of the Earth.  This then becomes a satellite, in orbit around the Earth.

#### <p>iframes are not supported by your browser.</p>

Satellites are bodies that orbit round the Earth.  They are put in to an orbit by powerful rockets.  Just like the Moon, they are all kept in orbit by the gravitational pull of the Earth.

In order to stay in orbit at a certain altitude (height) , the satellite must maintain the right speed to balance the pull of gravity. Lower the altitude of the satellite faster it would have to travel to stay up.  Those satellites which are high in the orbit travel at slower speeds, but take longer to complete 1 orbit of the Earth.

Although satellites travel very fast, some of them seem to be standing in one place, when viewed from the ground!  This happens when a satellite is put into an orbit at just the right altitude (36,000 Km above equator) and speed so that it takes 24 hours to circle round the Earth once.  This is the same time as the Earth, hence the satellite appears to float over one point.  See below.  These type of satellites are known to have a  GEO-STATIONARY or SYNCHRONOUS orbit.
